Wooden Body (Model : CIE/666)

Wooden Body (Model : CIE/666)

Product Description :

Housed in wooden body with sunmica finish, centrifugal clutch, collapsible driven generator handle, Anti-parallax mirror scale. Guard Terminal & externally accessible infinity adjuster are provided for instrument having insulation range 1000 MΩ & above.

Model Photo:

Technical Specifications & Features :

Scale Length 100 mm (approx.)
Rotation speed 160 or more r.p.m.
weight 4.1 kg (approx.)
Dimensions (in mm) 265x 165x 185 (approx.)
Accuracy As per ISS: 2992-1987

Range Available:Available from 100V to 5000V DC o/p voltage with suitable resistance range. Multiple ranges available at options provided with range selector switch.
